• Flush bottom ball vales ideally suitable for the free flowing of liquid where space below vessel, tank or reactor is insufficient. Unique design of Flush bottom ball valves assures “ Zero Dead Leg Area” above the ball where it tends to close.
• Valves available in the range of 25 NB to 150 NB and in BS, ANSI, DIN, standards.
• Screwed/ Bolted stuffing box (Gland), easily adjustable and with repackable service.
• Anti blow off proof stem.

* NOTE : Applications:
· API 600/API 602/API 603 For Gate Valve
· BS 1873/BS 1868/BS 5352 for Globae and Check Valve
· BS 5351/BS 4460/BS 5159 API 6D for Ball Valves
· API 598/BS 5146/API 607/ANSI B 16.34 for Inspection & Testing
· ANSI B16.10/ANSI B16.5/ANSI B16.34/ANSI B16.25/ANSI B16.11 for Dimensions
Also on Specific Requirement we offer valves as per DIN 3202/DIN 3300/BS Standars
